Specification:
Model No.
|
SE-RD716A
| |
system
|
operating system
|
embedded linux
|
system resources
|
Simultaneous multi-channel real-time recording, playback, network operation， USB backup
| |
interface
|
user interface
|
support 16-bit true color graphical menu interface and mouse operation
|
Video
|
vdieo compression
|
H.264
|
display quality
|
VGA、HDMI：1920*1080
| |
playback quality
|
1080N/960P/720P
| |
encode capacity
|
16*720P@25fps/16*1080P@12fps/16*960P@25fps
| |
decode capacity
|
8*1080N@25fps/16*1080N@12fps/
| |
Multi-mode Input
|
1.Analog: 16*720P；16*960P;16*1080P(AHD)
2.IPC: 8*1080P; 4*3 magepixel; 4*5 magapixel(IP) | |
motion detect
|
Zones: 192（16*12）detection zones,sensitivity: multi-level sensitivity (Only local channels)
| |
Record & playback
|
record mode
|
manual>alarm>motion detection>timing
|
local playback
|
16ch Playback:16*1080N@12fps 8ch Playback:8*1080N@25fps
| |
search mode
|
Time/calendar/event/channel search
| |
Storage & backup
|
HDD space for each channel
|
720P 20G/day；960P 12~20G/day*CH； Audio：691.2M/day*CH
|
record storage
|
HDD、network
| |
backup mode
|
Network backup、USB、SATA
| |
interface
|
video input
|
16ch BNC（1.0Vp-p,75Ω75Ω)
|
video output
|
1ch VGA，1ch HDMI
| |
audio input
|
2ch RCA(200-2800mV,30KΩ)
| |
audio output
|
1ch RCA(200-3000mV,5KΩ)
| |
net interface
|
RJ45 10M/100M
| |
PTZ control
|
One RS485 port, support multiple PTZ protocols
| |
usb
|
2 USB2.0 ports（save two front interface）
| |
hard disk
|
1 SATA ports（4T at most per one）
| |
others
|
Power supply
|
12V/3A
|
Working Temperature
|
0℃-＋55℃
| |
Working Humidity
|
10%－90%
| |
Atmospheric pressure
|
86kpa－106kpa
| |
dimension
|
335*230*48mm
| |
weight
|
2kg
|
